Description

StreetDemon Carburetor – Shiny/ShinyWICKEDPOWER! The all-new Street Demon® redefines what a true street carburetorshould be â?? clean looks, smooth drivability, and power on demand. Engineeredfor easy installation and everyday performance, the Street Demon features arevolutionary design that combines stable idle quality, crisp throttleresponse, and seamless transition from cruise to wide-open throttle. Its dualmounting pattern and optimized calibration make it Run-Readyâ?¢ for a widerange of engines, from mild small-blocks to stout big-blocks. The patentedGoggle Valve Secondary (GVSâ?¢) design delivers quick airflow when you need itmost, while the integrated fuel bowl and main body eliminate external leakpaths for long-term reliability. Finished in a bright, shiny coating thatcomplements any classic or modern engine bay, this 625 CFM Street Demon isready to bolt on and drive.This model of carburetor has the square bore flange bolt pattern. It can replace Holley, Edelbrock, Carter AFB, and Autolite style carburetors with 5 3/16″ x 5 5/8″ bolt pattern. If you have a spreadbore style intake manifold, you will need an adapter to install this carburetor. Similar to the Mr. Gasket #1932.

Barrel Qty:4

Barrels: 4

Body Color:Polished Aluminum

Body Finish: Polished

Body Material: Aluminum

Booster Design:Triple Stack

Booster: Triple Stack

Carburetor Use: Street

CFM Rating:625

Choke Type: Electric

Choke: Electric

Color:Polished Aluminum

Condition: New

Cubic Feet Per Minute Rating:625

Finish: Polished

Flange Shape:Square/Spread

Flange Type:Dual Square/Spread

Fuel Inlet: Single

Fuel Type: Gasoline

Fuel: Gasoline

Linkage Attached: Yes

Marine Approved: No

Material: Aluminum

Metering Rod Size: 60/52

Model: Street Demon

Performance Grade:Performance

Primary Main Jet Size:80

Primary Pump Nozzle Size: 31

Secondary Barrel Type: Vacuum

Secondary Main Jet Size:80

Step Up Spring: Green

Supercharger Compatible:No

Throttle Bore Diameter:1.375 inch

Vacuum Ports: 1 timed (spark) port, 2 full, and 1 PCV port
