Description

Flowmaster Flow FX Cat-Back Exhaust SystemThe Flowmaster® Flow FX Cat-back exhaust system is designed for 2004-2008 Ford F-150 trucks with 4.6L and 5.4L engines. This bolt-on system is manufactured using durable 409 stainless steel throughout, and features a 3.00-inch inlet pipe leading to a single inlet/dual outlet Flow FX® straight-through muffler for a deep, moderately aggressive sound and maximum performance. The dual 2.50-inch mandrel-bent tailpipes are custom routed to clear the factory spare tire and tow hitch without any clearance issues and exit out the sides behind the rear tires, which is ideal when towing so you don’t blow exhaust fumes on your boat, vehicle or trailer. The system is then finished off with a pair of large 4.50-inch black ceramic coated stainless steel tips, giving your F-150 an aggressive look to go with the sound of the Flow FX performance muffler. This system utilizes the factory hanger locations and includes detailed instructions and all necessary hardware for an easy at home installation. Notes: Fits all 2/4 wheel drive models and all wheelbases.2004-2008 Ford F-150 trucks, 4.6L, 5.4L engine, 2/4 Wheel drive, all Wheelbases.

Catalytic Converter Included: No

Catalytic Converter Quantity: 0

Clamping Type: Flat Band

Clamps Included: Yes

Exhaust Series:Flow FX

Exhaust Tip Color: Black

Exhaust Tip Connection: Clamp-On

Exhaust Tip Cut: Angled

Exhaust Tip Diameter: 4.50″

Exhaust Tip Edge: Rolled Edge

Exhaust Tip Finish: Black Ceramic Coating

Exhaust Tip Intercooled: No

Exhaust Tip Length: 11.00″

Exhaust Tip Material: 304 Stainless Steel

Exhaust Tip Quantity: 2

Exhaust Tip Resonated: No

Exhaust Tip Shape: Round

Exhaust Tip Wall: Single Wall

Exit Style: Dual Out Side

Finish: Natural

Gasket Or Seal Included: No

Grade Type: Performance

Hangers Included: Yes

Inlet Type: Clamp-On

Main Piping Diameter: 2.50″

Mount Type: Uses Factory Hanger

Mounting Bracket Included: Yes

Muffler Body Height: 4.00 Inch

Muffler Body Length: 18.00 Inch

Muffler Body Material: 409 Stainless Steel

Muffler Body Shape: Oval

Muffler Body Width: 9.00 Inch

Muffler Finish: Natural

Muffler Flanged Inlet: No

Muffler Flanged Outlet: No

Muffler Included: Yes

Muffler Inlet Connection: Slip-Fit

Muffler Inlet Inside Diameter: 3.00 Inch

Muffler Inlet Location: Center

Muffler Inlet Outside Diameter: 3.13 Inch

Muffler Outlet Connection: Slip-Fit

Muffler Outlet Diameter: 2.50 Inch

Muffler Outlet Location: Dual

Muffler Outlet Quantity: 1

Muffler Quantity: 1

Muffler Type: Absorption

Pipe Color: Silver

Pipe Material: 409 Stainless Steel

Sound Level: Moderate

Spring Bolt Kit Included: No

Tail Pipe Outlet Outside Diameter: 2.50 Inch

Tail Pipe Quantity: 2

Tail Pipe Quantity: Dual

Tail Pipe Tapered Outlet: No

Tip Logo: Embossed

Type: Cat-Back

Valve Included: No

Valve Type: Not Applicable
