Description

Sniper EFI Fuel Tank System 255 LPHFuel tank is a direct fit for your application with no body modifications necessary. The kit includes the tank, a 255 lph fuel pump, fuel level sender, new tank straps, and the filler neck. The tank is powder coated for corrosion resistance and great looks. This notched corner tank is perfect for mini-tub applications. Both corners are notched 7″ in and 7″ back for better tire and exhaust clearance. The rear of the tank is the stock depth while the front of the tank is 1″ deeper than stock. The 255 LPH fuel pump supports up to 550 EFI (@ 60 PSI at 13.5 Volts / 10.4 AMP Draw).When installing sending units, please remember to rotate the unit until the mounting holes align with the flange holes in the tank.

Application: 1968-1972 EL Camino / Sprint

Attached Sump: Yes

Baffled Sump: Yes

Color: Silver

Drain Plug: No

Filler Neck Attached: No

Finish: Powdercoated

Free Flow LPH: 255

Fuel Sending Unit Ohms: 0-90 Ohms

Fuel System Compatibility: Electronic Fuel Injection

Fuel System Type: Gasoline

Fuel Tank Coating: Powder Coated

Gallon Capacity: 20

Grade Type: Performance

Lock Ring Included: Yes

Material: Steel

Maximum Flow Rating: 255 LPH

Mounting Straps Included: Yes

New Straps Included: Yes

O-Ring Included: Yes

Resistance Ohms Empty: 0 82

Resistance Ohms Full: 90 82

Sending Unit Included: Yes

Tank Capacity: 20 GA

Tank Color: Gray

Tank Material: Steel
