Description

Sniper EFI Fuel Tank System 255 LPHHolley and Sniper will help you to complete your EFI swap with our new EFI Conversion Fuel Tanks. Each tank is a direct fit for your application-no modifications necessary. The kit includes the tank, a 255 lph fuel pump, internal baffling, and a fuel level sender. The tank is powder coated for corrosion resistance and great looks. These tank kits are a complete solution for your EFI project!***Steel filler neck that extends to rear valance is not included. You must use your existing stock filler neck or purchase one through restoration suppliers.***These tanks are perfect for your next classic truck EFI conversion project as well.Supports up to 550 EFI (@ 60 PSI at 13.5 Volts / 10.4 AMP Draw)Size is: 32-5/8″ x 24-1/2″ x 9-3/4″For a better seal use Permatex Indian Head Gasket Shellac Compound or Aviation Form-A-Gasket sealant on the gasket and screws.When installing sending units, please remember to rotate the unit until the mounting holes align with the flange holes in the tank.

Application: 1969-1970 Ford Mustang

Attached Sump: Yes

Baffled Sump: Yes

Color: Silver

Drain Plug: No

Filler Neck Attached: No

Finish: Powdercoated

Free Flow LPH: 255

Fuel Sending Unit Ohms: 73-10 Ohms

Fuel System Compatibility: Electronic Fuel Injection

Fuel System Type: Gasoline

Fuel Tank Coating: Powder Coated

Gallon Capacity: 22

Grade Type: Performance

Lock Ring Included: Yes

Material: Steel

Maximum Flow Rating: 255 LPH

Mounting Straps Included: Yes

New Straps Included: No

O-Ring Included: Yes

Resistance Ohms Empty: 73 82

Resistance Ohms Full: 10 82

Sending Unit Included: Yes

Tank Capacity: 22 GA

Tank Color: Gray

Tank Material: Steel
