Description

Sniper EFI Fuel Tank System 255 LPHEach tank is a direct fit for your application with no body modifications necessary. The kit includes the tank, a 255 lph fuel pump, a fuel level sender, and new tank straps. The tank is powder coated for corrosion resistance and great looks. This model has notched front corners for additional tire and exhaust clearance. This notched corner 69 Camaro and Firebird tank is perfect for mini-tub applications. The front of this tank is narrowed to 27″ to clear up to a 345 tire and 3″ exhaust. To help regain fuel capacity from the notched corners this tank is 1″ deeper than stock. Even if you do not have a mini-tubbed car this tank will work on a stock car where you need a little more clearance for exhaust. The 255 LPH fuel pump supports up to 550 EFI (@ 60 PSI at 13.5 Volts / 10.4 AMP Draw).When installing sending units, please remember to rotate the unit until the mounting holes align with the flange holes in the tank.

Application: 1969 Chevrolet Camaro/Pontiac Firebird

Attached Sump: Yes

Baffled Sump: Yes

Color: Silver

Drain Plug: No

Filler Neck Attached: No

Finish: Powdercoated

Free Flow LPH: 255

Fuel Sending Unit Ohms: 0-90 Ohms

Fuel System Compatibility: Electronic Fuel Injection

Fuel System Type: Gasoline

Fuel Tank Coating: Powder Coated

Gallon Capacity: 18

Grade Type: Performance

Lock Ring Included: Yes

Material: Steel

Maximum Flow Rating: 255 LPH

Mounting Straps Included: No

New Straps Included: Yes

O-Ring Included: Yes

Resistance Ohms Empty: 0 82

Resistance Ohms Full: 90 82

Sending Unit Included: Yes

Tank Capacity: 18 GA

Tank Color: Gray

Tank Material: Steel
