Description

A staple in the drag race community, features a built-in 2 step rev control and its famous high output spark energy. Now in Black!You’ll recognize the 7AL-2 Plus Ignition Control now in Black! As its predecessor is the most popular ignition control used in drag racing. The ”Plus” model updates the original 7AL-2 with improved internal components plus our engineers added a 2-Step Rev Control and a useful diagnostic LED.Visually, you’ll notice the two terminal strips that allow for easier wiring in your race car. The LED over the power connections will come in handy for troubleshooting as it flashes only when the coil fires. That way you know that the coil, the trigger source and ignition are all functioning properly. The mounting pattern is the same as the 7AL-2 and is supplied with vibration mounts and a few rpm modules.Racers will be happy to see that the updated components up the voltage output and spark energy! Over 40% more spark energy in fact!6 Amps Per 6,000 RPM 12 Amps at 12,000 RPMBuilt-in 2-step rev controlSupplied with 3000, 7000, 8000, 9000 RPM ChipsTerminal strips for convenient hookup12-18 Volts, Negative GroundDiagnostic Troubleshooting LEDOperates on 4, 6 or 8-cylinder engines14,000 RPM with 14.4 Volts

Color: Black

Connector Gender: Terminal Strip

Connector Quantity: 2

Current Draw: 12,000 RPM

Current Draw: 6000 RPM

Features: Rev Limiter

Grade Type: Race

Height: 5.75 in

Ignition Type: Performance

Length: 8.25″

Maximum RPM: 14,000 RPM

Mount Type: Surface Mount

Mounting Hardware Included: Yes

Primary Voltage: 570

Secondary Voltage: 47,000 RPM

Spark Energy (mJ per spark): 160

Terminal Gender: Terminal Strip

Terminal Quantity: 10

Voltage Required: 12-18

Width: 3.75 Inch
